Features
- All exterior components are 300-series stainless steel; All sealing components are Viton® for superior chemical resistance
- End shields are O-ring sealed to the frame; Double lip shaft seals on both ends of TEFC motors (shaft end only on TENV motors)
- Double-sealed bearings are pre-lubricated with moisture-resistant high temperature grease for long life
- Interior coatings applied to rotor and stator protect against corrosion; Ease to clean construction is BISSC Certified for bakery applications
- Removable hydrophobic breathers in opposite shaft end bell and conduit box equalize pressure without allowing moisture to enter
- LEESON’s exclusive IRIS™ Inverter-Rated Insulation System provides extra protection and long life, especially in inverter-driven applications
- All Washdown Duty motors have Class F Insulation
- Full fact nameplate is laser etched on the motor frame
General Specifications
| UPC: | 691720343142 | Weight: | 59.00 LB |
| Packaged Length: | 19.5 IN | Packaged Width: | 10.44 IN |
| Packaged Height: | 10.88 IN |
Nameplate Specifications
| Output HP: | 1 Hp | Output KW: | 0.75 kW |
| Voltage: | 180 V | Current: | 5.0 A |
| Speed: | 1750 rpm | Service Factor: | 1 |
| Efficiency: | 85.3 % | Duty: | Continuous |
| Insulation Class: | F | Frame: | ZS56C |
| Enclosure: | Totally Enclosed Fan Cooled | Thermal Protection: | No |
| Ambient Temperature: | 40 °C | Drive End Bearing Size: | 6205 |
| Opp Drive End Bearing Size: | 6203 | UL: | Recognized |
| CSA: | Y | CE: | N |
Technical Specifications
| Rotation: | Reversible | Mounting: | Round |
| Overall Length: | 13.87 in | Frame Length: | 9.63 in |
| Shaft Diameter: | 0.625 in | Shaft Extension: | 2.05 in |
Speed & Load Characteristics
