Features
- Low starting torque
- Energy efficient
General Specifications
| UPC: | 786674016317 | Weight: | 38.00 LB |
| Packaged Length: | 16 IN | Packaged Width: | 8 IN |
| Packaged Height: | 10 IN |
Nameplate Specifications
| Output HP: | 1.0 Hp | Output KW: | 0.75 kW |
| Frequency: | 60 Hz | Voltage: | 115/230 V |
| Current: | 9.6/4.8 A | Speed: | 1725 rpm |
| Service Factor: | 1 | Phase: | 1 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | M56H | Enclosure: | Totally Enclosed Air Over |
| Thermal Protection: | Thermally Protected | Ambient Temperature: | 40 °C |
| UL: | Recognized | CSA: | Y |
| CE: | N |
Technical Specifications
| Electrical Type: | Capacitor Start, Capacitor Run, Low Starting Torque, Single Or Dual Voltage | Starting Method: | Across The Line |
| Poles: | 4 | Rotation: | Reversible Clockwise |
| Mounting: | Rigid Base | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Keyed | Overall Length: | 12.69 in |
| Frame Length: | 6.75 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 1.94 in |
