Features
- Weatherproof features for washdown
- Cast iron NEMA "C" end bracket
- Stainless steel shaft
- Auto overload protector
General Specifications
| UPC: | 786674061324 | Weight: | 38.00 LB |
| Packaged Length: | 16 IN | Packaged Width: | 8 IN |
| Packaged Height: | 10 IN |
Nameplate Specifications
| Output HP: | 3/4 Hp | Output KW: | 0.56 kW |
| Frequency: | 60 Hz | Voltage: | 208-230 V |
| Current: | 2.5-2.4 A | Speed: | 3450 rpm |
| Service Factor: | 1 | Phase: | 3 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | L56HCZ | Enclosure: | Totally Enclosed Non Ventilated |
| Thermal Protection: | Thermally Protected | Ambient Temperature: | 40 °C |
| UL: | Recognized | CSA: | Y |
| CE: | N |
Technical Specifications
| Electrical Type: | Polyphase | Starting Method: | Across The Line |
| Poles: | 2 | Rotation: | Reversible |
| Mounting: | Rigid Base | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Keyed | Overall Length: | 12.20 in |
| Frame Length: | 6.25 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 1.88 in |
