Features
- Weatherproof features for washdown
- Cast iron NEMA "C" end bracket
- Stainless steel shaft
- Auto overload protector
- ACME right hand threads
General Specifications
| UPC: | 786674060570 | Weight: | 26.00 LB |
| Packaged Length: | 15.5 IN | Packaged Width: | 10.5 IN |
| Packaged Height: | 10 IN |
Nameplate Specifications
| Output HP: | 1/2 Hp | Output KW: | 0.37 kW |
| Frequency: | 60 Hz | Voltage: | 208-230/460 V |
| Current: | 1.9-1.8/0.9 A | Speed: | 3450 rpm |
| Service Factor: | 1 | Phase: | 3 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 56HCZ | Enclosure: | Totally Enclosed Non Ventilated |
| Thermal Protection: | Thermally Protected | Ambient Temperature: | 40 °C |
| UL: | Recognized | CSA: | Y |
| CE: | N |
Technical Specifications
| Electrical Type: | Polyphase, Induction Type, Single Or Dual Voltage | Starting Method: | Across The Line |
| Poles: | 2 | Rotation: | Clockwise/Counterclockwise |
| Mounting: | Rigid Base | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Threaded | Overall Length: | 11.93 in |
| Frame Length: | 5.75 in | Shaft Diameter: | 0.500 in |
| Shaft Extension: | 2.30 in |
