Features
Features
- Meets or exceeds all USA mandated effciencies
- Rolled steel construction
- 60/50 Hz at next horsepower
General Specifications
General Specifications
| Model : | Catalog No : | OB3204V1 | |
| Part Description : | 2,1725,ODP,56HZ,3/60/200-230/460 | Category : | Open Drip Proof (ODP) |
| Stock : | Yes |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 2 Hp | Output KW : | 1.5 kW |
| Frequency : | 60 Hz | Voltage : | 200-230/460 V |
| Current : | 6.8/3.4 A | Speed : | 1725 rpm |
| Service Factor : | 1.15 | Phase : | 3 |
| Duty : | Continuous | Insulation Class : | B |
| Frame : | 56HZ | Enclosure : | Open Drip Proof |
| Overload Protector : | None | Ambient Temperature : | 40 °C |
| UL : | Recognized | CSA : | Y |
| CE : | N |
Technical Specifications
Technical Specifications
| Electrical Type : | Polyphase | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Reversible |
| Mounting : | Rigid Base | Drive End Bearing : | Ball |
| Opp Drive End Bearing : | Ball | Frame Material : | Rolled Steel |
| Shaft Type : | Keyed | Overall Length : | 13.22 in |
| Frame Length : | 8.19 in | Shaft Diameter : | 0.874 in |
| Shaft Extension : | 2.38 in | UPC : | 786674027092 |
| Weight : | 33.00 LB |
