Features
- Reversible
- Cushion ring, no base and C-face
- No protector
General Specifications
| UPC: | 786674056542 | Weight: | 42.00 LB |
| Packaged Length: | 19 IN | Packaged Width: | 10 IN |
| Packaged Height: | 9 IN |
Nameplate Specifications
| Output HP: | 3.0 Hp | Output KW: | 2.2 kW |
| Frequency: | 60 Hz | Voltage: | 460/208-230 V |
| Current: | 4.4/9.0-8.8 A | Speed: | 1725 rpm |
| Service Factor: | 1.15 | Phase: | 3 |
| Duty: | Continuous | Insulation Class: | F |
| Frame: | R56Y | Enclosure: | Drip Proof |
| Thermal Protection: | None | Ambient Temperature: | 40 °C |
| UL: | Recognized | CSA: | Y |
| CE: | N |
Technical Specifications
| Electrical Type: | Polyphase, Induction Type, Single Or Dual Voltage | Starting Method: | Across The Line |
| Poles: | 4 | Rotation: | Reversible Counterclockwise |
| Mounting: | Cushion Ring | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Keyed | Overall Length: | 14.56 in |
| Frame Length: | 8.75 in | Shaft Diameter: | 0.875 in |
| Shaft Extension: | 2.31 in |
