Features
- Internally mounted capacitor
- Sealed switch design
- Threaded shaft
General Specifications
| Model : | Catalog No : | T1032 | |
| Part Description : | 1/3,3450,ODP,56J,1/60/230/115 | Category : | Jet Pump |
| Stock : | Yes |
Nameplate Specifications
| Output HP : | 1/3 Hp | Output KW : | 0.25 kW |
| Frequency : | 60 Hz | Voltage : | 230/115 V |
| Current : | 3.4/6.8 A | Speed : | 3450 rpm |
| Service Factor : | 1.8 | Phase : | 1 |
| Duty : | Continuous | Insulation Class : | B |
| Frame : | 56J | Enclosure : | Open Drip Proof |
| Overload Protector : | Automatic | Ambient Temperature : | 40 °C |
| UL : | No | CSA : | Y |
| CE : | N |
Technical Specifications
| Electrical Type : | Capacitor Start Induction Run | Starting Method : | Across The Line |
| Poles : | 2 | Rotation : | Counterclockwise Pump End |
| Mounting : | Round | Drive End Bearing : | Ball |
| Opp Drive End Bearing : | Ball | Frame Material : | Rolled Steel |
| Shaft Type : | Threaded | Overall Length : | 10.81 in |
| Frame Length : | 5.00 in | Shaft Diameter : | 0.625 in |
| Shaft Extension : | 2.433 in | UPC : | 786674032034 |
| Weight : | 16.00 LB |
