CEM3714T Baldor 10HP Electric Motor, 1800RPM

$1,742.97 USD

Shipping calculated at checkout

Baldor Electric Company SKU: CEM3714T Barcode: 781568541470

30 Day
Return Policy

Ships Fast
in 24 hours

TEFC, 215TC Frame, 230/460V 3-Phase 60Hz, 3752M, C-Face, Foot Mounted

Description Product Specs Manufacturer

Specifications

Specs

Output10.000 hp
Phase3
Synchronous Speed1,800 rpm
Frequency60.00 Hz
Voltage460 V
230 V
Frame MaterialSteel
Frame215TC
XP Class and GroupNONE
XP DivisionNot Applicable
BrandBaldor-Reliance
Agency ApprovalsCSA
CSA EEV
UR
Ambient Temperature40 °C
Auxillary BoxNo Auxillary Box
Auxillary Box Lead TerminationNone
Base IndicatorRigid
Bearing Grease TypePOLYREX EM (-20F +300F)
BlowerNone
Current25.4 A @ 208 V
24.0 A @ 230 V
12.0 A @ 460 V
Design CodeA
Drip CoverNo Drip Cover
Duty RatingCONT
Efficiency @ 100% Load91.7%
Electrically Isolated BearingNot Electrically Isolated
Feedback DeviceNo feedback
Front Face CodeStandard
Front Shaft IndicatorNone
Heater IndicatorNo heater
High Voltage Full Load Amps12.0 A
Insulation ClassF
Inverter CodeInverter ready
KVA CodeK
Lifting LugsStandard Lifting Lugs
Locked Bearing IndicatorLocked Bearing
Motor Lead ExitKO Box
Motor Lead Quantity/Wire Size9 @ 14 AWG
Motor Lead TerminationFlying Leads
Motor StandardsNEMA
Motor Type3752M
Number of Poles4
Overall Length21.26 in
Power Factor85
Product FamilyGeneral Purpose
Pulley End Bearing TypeBall
Pulley Face CodeC-Face
Pulley Shaft IndicatorStandard
Rodent ScreenNone
Service Factor1.15
Shaft Diameter1.375 in
Shaft Extension LocationPulley End
Shaft Ground IndicatorNo Shaft Grounding
Shaft RotationReversible
Shaft Slinger IndicatorNo Slinger
Speed1,770 rpm
Speed CodeSingle Speed
Starting MethodDirect on line
Thermal Device - BearingNone
Thermal Device - WindingNone
Vibration Sensor IndicatorNo Vibration Sensor
Winding Thermal 1None
Winding Thermal 2None

Applications

  • Fans
  • Pumps
  • Blowers
  • Conveyors
  • Compressors
  • Industrial machines
  • Other general purpose applications

Features

Nameplate

Nameplate

CAT.NO. CEM3714T
SPEC 37G814S518G2
HP 10
VOLTS 230/460
AMPS 24/12
RPM 1770
FRAME 215TC HZ 60 PH 3
SF 1.15 CODE K DES A CLASS F
NEMA NOM. EFF 91.7 PF 85
RATING 40C AMB-CONT
CC 010A USABLE AT 208V 25.4
ENCL TEFC SER
DE 6307 ODE 6206
VPWM INVERTER READY
CT6-60H(10:1)VT3-60H(20:1
50Hz 10HP 190/380V 29.2/14.6A SF1.0
NP3441LUA

Performance

Performance

Performance at 460 V, 60 Hz, 10 hp

Typical performance; not guaranteed values.

General Characteristics

Full Load Torque0 LB-FT
No-Load Current0 A
Line-Line Res. @ 25° C0.937 Ohms A Ph / 0 Ohms B Ph
Temp. Rise @ Rated Load63° C
Temp. Rise @ S.F. Load77° C
Start ConfigurationDOL
Break-Down Torque134 LB-FT
Pull-Up Torque49.2 LB-FT
Locked-Rotor Torque68.7 LB-FT
Starting Current103 A

Load Characteristics

Rated Load 0% 25% 50% 75% 100% 125% 150% S.F.
Power Factor 5.0 42.0 64.0 76.0 82.0 86.0 88.0 84.0
Efficiency 0.0 88.6 92.4 92.7 91.8 90.8 88.9 91.2
Speed (RPM) 1,799 1,794 1,787 1,780 1,772 1,763 1,753 1,767
Line Amps 5.49 6.14 7.80 9.90 12.30 15.00 17.90 13.90
