Features
- Standard efficient ratings
- Inverter rated
- Shielded ball bearings for direct coupled applications. Contact your local sales office for belted load applications
- Rolled steel frame material designs
- Dynamically balanced rotors
- Torques exceed NEMA performance standards
- UL recognized and CSA certified
- Continuous duty
General Specifications
| Model : | C6T17FC7G | Catalog No : | 110177.00 |
| Part Description : | 3/4HP..1725RPM.56.TEFC./575V.3PH.60HZ.CONT.NOT.40C.1.15SF.C FACE.575 VOLT.C6T17FC7G | Category : | 575 Volts |
| Stock : | No |
Nameplate Specifications
| Output HP : | 0.75 Hp | Output KW : | 0.56 kW |
| Frequency : | 60 Hz | Voltage : | 575 V |
| Current : | 1.1 A | Speed : | 1725 rpm |
| Service Factor : | 1.15 | Phase : | 3 |
| Efficiency : | 77 % | Duty : | Continuous |
| Insulation Class : | B | Design Code : | B |
| KVA Code : | K | Frame : | 56C |
| Enclosure : | Totally Enclosed Fan Cooled | Overload Protector : | No |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6203 |
| Opp Drive End Bearing Size : | 6203 | UL : | Recognized |
| CSA : | Y | CE : | N |
| IP Code : | 54 |
Technical Specifications
| Electrical Type : | Squirrel Cage Induction Run | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Reversible |
| Mounting : | Round | Motor Orientation : | HORIZONTAL |
| Drive End Bearing : | BALL | Opp Drive End Bearing : | BALL |
| Frame Material : | Rolled Steel | Shaft Type : | NEMA 56 |
| Overall Length : | 10.48 in | Frame Length : | 5.00 in |
| Shaft Diameter : | 0.625 in | Shaft Extension : | 1.88 in |
| Assembly/Box Mounting : | F1 ONLY | UPC : | 691720008027 |
| Weight : | 24.00 LB |
Speed Characteristics
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | Torque (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Locked-Rotor | 6.45 | 6.60 | 293.0 | 0 | 0.75 | |||
| Full Load | 1.12 | 2.25 | 100.0 | 0 | 0.75 | |||
| Break-Down | 0.00 | 8.35 | 371.0 | 0 | 0.75 | |||
| Pull-Up | 0.00 | 6.45 | 287.0 | 0 | 0.75 |
Load Characteristics
- % of Rated Load
- Current (Amps)
- Rated Output (KW)
- Efficiency (%)
- Power Factor (%)
- Speed (RPM)
- Temp. Rise @ FL
- Torque (ft-lb)
- 0 %
- 0.88
- 0.000
- 0.0
- 0.0
- 0
- 0.0
- 0.00
- 25 %
- 0.00
- 0.000
- 55.4
- 28.6
- 0
- 0.0
- 0.00
- 50 %
- 0.00
- 0.000
- 70.9
- 42.3
- 0
- 0.0
- 0.00
- 75 %
- 0.00
- 0.000
- 74.7
- 54.5
- 0
- 0.0
- 0.00
- 100 %
- 0.00
- 0.000
- 77.0
- 65.0
- 0
- 60.0
- 0.00
- 125 %
- 0.00
- 0.000
- 0.0
- 0.0
- 0
- 0.0
- 0.00
- 150 %
- 0.00
- 0.000
- 0.0
- 0.0
- 0
- 0.0
- 0.00
