| Frame | 182/4JP |
|---|---|
| Output | 5 HP (3.7 kW) |
| Number of Poles | 4 |
| Frequency | 60 Hz |
| Rated speed | 1735 rpm |
| Slip | 3.61 % |
| Rated voltage | 115/230 V |
| Rated current | 44.8/22.4 A |
| L. R. Amperes | 349/175 A |
| LRC | 7.8x(Code K) |
| No load current | 19.6/9.80 A |
| Rated torque | 15.1 ft.lb |
| Locked rotor torque | 280 % |
| Breakdown torque | 245 % |
| Locked rotor time | 14s (cold) 8s (hot) |
|---|---|
| Moment of inertia (J) | 0.4343 sq.ft.lb |
| Insulation Class | F |
| Service factor | 1.15 |
| Temperature rise | 80 K |
| Duty Cycle | Cont.(S1) |
| Starting Method | Direct On Line |
| Ambient temperature | -20°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Degree of Protection | IP55 |
| Enclosure | IC411 - TEFC |
| Mounting | F-1 |
| Rotation¹ | Both (CW and CCW) |
| Approx. weight³ | 119 lb |
(1) Looking the motor from the shaft end.; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.
Efficiency
| 50% | 75% | 100% |
|---|---|---|
| 70.0 | 76.0 | 78.0 |
Power factor
| 50% | 75% | 100% |
|---|---|---|
| 0.83 | 0.89 | 0.92 |
