Electric Motors
| Frame | 132M |
|---|---|
| Output | 4 HP (3 kW) |
| Number of Poles | 8 |
| Frequency | 50 Hz |
| Rated speed | 710 rpm |
| Slip | 5.33 % |
| Rated voltage | 380 V |
| Rated current | 7.48 A |
| L. R. Amperes | 47.9 A |
| LRC | 6.4 |
| No load current | 4.40 A |
| Rated torque | 29.2 ft.lb |
| Locked rotor torque | 229 % |
| Breakdown torque | 250 % |
| Locked rotor time | 37s (cold) 21s (hot) |
| Moment of inertia (J) | 1.99 sq.ft.lb |
|---|---|
| Design | N |
| Insulation Class | F |
| Service factor | 1.00 |
| Temperature rise | 80 K |
| Duty Cycle | S1 |
| Starting Method | Direct On Line |
| Ambient temperature | -20°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Degree of Protection | IP55 |
| Enclosure | IC411 - TEFC |
| Mounting | B3L(E) |
| Rotation¹ | Both (CW and CCW) |
| Noise level² | 48.0 dB(A) |
| Approx. weight³ | 152 lb |
(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.
Efficiency
| 50% | 75% | 100% |
|---|---|---|
| 82.5 | 83.0 | 83.5 |
Power factor
| 50% | 75% | 100% |
|---|---|---|
| 0.52 | 0.65 | 0.73 |
| Frame | 132M |
|---|---|
| Output | 4 HP (3 kW) |
| Number of Poles | 8 |
| Frequency | 50 Hz |
| Rated speed | 715 rpm |
| Slip | 4.67 % |
| Rated voltage | 400 V |
| Rated current | 7.41 A |
| L. R. Amperes | 51.1 A |
| LRC | 6.9 |
| No load current | 4.80 A |
| Rated torque | 29.0 ft.lb |
| Locked rotor torque | 270 % |
| Breakdown torque | 290 % |
| Locked rotor time | 37s (cold) 21s (hot) |
| Moment of inertia (J) | 1.99 sq.ft.lb |
|---|---|
| Design | N |
| Insulation Class | F |
| Service factor | 1.00 |
| Temperature rise | 80 K |
| Duty Cycle | S1 |
| Starting Method | Direct On Line |
| Ambient temperature | -20°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Degree of Protection | IP55 |
| Enclosure | IC411 - TEFC |
| Mounting | B3L(E) |
| Rotation¹ | Both (CW and CCW) |
| Noise level² | 48.0 dB(A) |
| Approx. weight³ | 152 lb |
(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.
Efficiency
| 50% | 75% | 100% |
|---|---|---|
| 82.5 | 83.0 | 83.5 |
Power factor
| 50% | 75% | 100% |
|---|---|---|
| 0.47 | 0.61 | 0.70 |
| Frame | 132M |
|---|---|
| Output | 4 HP (3 kW) |
| Number of Poles | 8 |
| Frequency | 50 Hz |
| Rated speed | 720 rpm |
| Slip | 4.00 % |
| Rated voltage | 415 V |
| Rated current | 7.44 A |
| L. R. Amperes | 55.1 A |
| LRC | 7.4 |
| No load current | 5.20 A |
| Rated torque | 28.8 ft.lb |
| Locked rotor torque | 300 % |
| Breakdown torque | 320 % |
| Locked rotor time | 37s (cold) 21s (hot) |
| Moment of inertia (J) | 1.99 sq.ft.lb |
|---|---|
| Design | N |
| Insulation Class | F |
| Service factor | 1.00 |
| Temperature rise | 80 K |
| Duty Cycle | S1 |
| Starting Method | Direct On Line |
| Ambient temperature | -20°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Degree of Protection | IP55 |
| Enclosure | IC411 - TEFC |
| Mounting | B3L(E) |
| Rotation¹ | Both (CW and CCW) |
| Noise level² | 48.0 dB(A) |
| Approx. weight³ | 152 lb |
(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.
Efficiency
| 50% | 75% | 100% |
|---|---|---|
| 81.5 | 83.2 | 83.7 |
Power factor
| 50% | 75% | 100% |
|---|---|---|
| 0.43 | 0.57 | 0.67 |
| Frame | 132M |
|---|---|
| Output | 4 HP (3 kW) |
| Number of Poles | 8 |
| Frequency | 60 Hz |
| Rated speed | 870 rpm |
| Slip | 3.33 % |
| Rated voltage | 460 V |
| Rated current | 6.50 A |
| L. R. Amperes | 50.7 A |
| LRC | 7.8 |
| No load current | 4.50 A |
| Rated torque | 23.8 ft.lb |
| Locked rotor torque | 320 % |
| Breakdown torque | 340 % |
| Locked rotor time | 46s (cold) 26s (hot) |
| Moment of inertia (J) | 1.99 sq.ft.lb |
|---|---|
| Design | N |
| Insulation Class | F |
| Service factor | 1.25 |
| Temperature rise | 80 K |
| Duty Cycle | S1 |
| Starting Method | Direct On Line |
| Ambient temperature | -20°C to +40°C |
| Altitude | 1000 m.a.s.l. |
| Degree of Protection | IP55 |
| Enclosure | IC411 - TEFC |
| Mounting | B3L(E) |
| Rotation¹ | Both (CW and CCW) |
| Noise level² | 52.0 dB(A) |
| Approx. weight³ | 152 lb |
(1) Looking the motor from the shaft end.; (2) Measured at 1m and with tolerance of +3dB(A).; (3) Approximate weight, subject to be changed after manufacturing process.; (4) At 100% of full load.
Efficiency
| 50% | 75% | 100% |
|---|---|---|
| 83.5 | 85.0 | 86.5 |
Power factor
| 50% | 75% | 100% |
|---|---|---|
| 0.45 | 0.58 | 0.67 |
Features
| Frame Material | Aluminum |
|---|---|
| Impregnation Method | Dip and Bake Polyester |
| Main terminal box hole | 2xM32x1,5 |
| Terminal Block | BMC - 6 pins |
| Shaft Locking Device | Without |
| Drain | Rubber, automatic |
| Shaft Material | SAE 1040/45 Carbon Steel |
| Painting | RAL 5009 207A (ISO 12944 - C2) |
| Grounding Lugs | Single |
| Fan Cover material | Steel |
| Tropicalized Painting | Without |
| Fan material | Plastic |
| Bearing cap | No-Without Bearing Cap |
| Drip Cover | Without |
