Specifications
| Manufacturer | Teco-Westinghouse |
|---|---|
| Catalog Number | NP0022 |
| Type | AEHH8P |
| Power | 2 HP 1.49 kW |
| Voltage | 190/380 VAC @ 50Hz 230/460 VAC @ 60Hz |
| Phase | 3 Phase |
| RPM | 2835 RPM @ 50Hz 3450 RPM @ 60Hz |
| Full Load Amps | Amps |
| Full Load Efficiency | % |
| Full Load Power Factor | % |
| Service Factor | 1.15 @ 60Hz 1.00 @ 50Hz |
| Frame | 145T Cast Iron |
| Rating | Continuous |
| Mounting | Foot Mount |
| Enclosure | TEFC |
| Insulation Class | F |
| Ambient | 40°C |
| Design | B |
| Approximate Weight | 53 lbs |
| Country of Origin | Taiwan |
| Warranty | 36 Months |
Features
- Totally Enclosed Fan Cooled (IP54 Rating)
- Meets or Exceeds NEMA Premium Efficiency Levels
- Department of Energy Efficiency Certificate #CC002A
- 36 Month Warranty from Date of Manufacture
- 60 Hz – 230/ 460V (Usable on 208V). 150 hp and Larger is 460V Only
- 1.15 Service Factor – Continuous
- 50 Hz Data on Nameplate - 190/ 380V at 1.0 S.F. 150 hp and Larger is 380V Only at 1.0 S.F.
- Class F Insulation with Phenolic Alkyd Resin Varnish – 2 Dips and Bakes
- Class B Temperature Rise
- Oversized Main Conduit Box Rotatable in 90 Degree Increments – Fully Gasketed F1 Mounted. F2 Available - See EXTRAS/OPTIONS Below
- Designed for 40°C Ambient Temperature - Note (1)
- Designed for 3300 ft. Elevation - Note (2)
- Factory Self Certified for Class 1, Div. 2, Groups B, C, D; Temp Code T3C, 400T and Below - Note (3)
- Bidirectional Rotation
- Cast Iron Frame, End Brackets, Pressed Steel Fan Cover and Conduit Box
- Dual Drilled Feet - Longer Frames (i.e. 145T Drilled also for 143T
- 1045 Carbon Steel Shaft
- Aluminum Die Cast Squirrel Cage Rotor Construction
- Paint System: Phenolic Rust Proof Base Plus Polyurethane Top Coat
- Paint Color: Blue Gray – Munsell 7.5 BG 3.5/ .05
- Vacuum De-Gassed Re-Greasable Bearings for Frames 280TS-449T/TS with Polyrex EM Grease
- Double Shielded Bearings on Frames 140T-280T Pre-Packed with MULTEMP SRL Grease
- Automatic Grease Discharge on Frames on Re-Greaseable Motors
- Labyrinth Type Metal Flinger on Both Ends for Frames 280TS-449T/TS
Rubber Flinger on Drive-End for Frames 140T - 280T - Cast Iron Inner and Outer Bearing Caps for Frames 280TS-449T/TS
- Grounding Terminal Inside Main Box
- Stainless Steel Nameplate
- Inverter Duty Magnet Wire Capable of Withstanding Voltage Spikes of Up to 2200 Volts
- Precautions should be taken to eliminate or reduce shaft currents that may be imposed on the motor by the VFD as stated per NEMA MG1 Part 31.4.4.3.
- Speed Ranges: 20:1 VT, 10:1 CT
- VFD Rated per NEMA MG1, Part 31.4.4.2.
- 9 Leads - 5 hp and Below
12 Leads 7.5 hp - 125 hp
6 Leads - 15
Applications
- Fans & Blowers
- Pumps
- Crushers
- Compressors
- Mixers
- Conveyors
