Specifications
| Brand | Teco-Westinghouse |
|---|---|
| Catalog | JPP0026 |
| Type | AEHH8NJP |
| Frame | 184JP |
| Output Power | 2 HP 1.5 kW |
| RPM | 1200 RPM |
| Voltage | 208-230/460VAC 60Hz 3-Phase |
| Enclosure | TEFC |
| Rated Ambient | 40°C |
| Insulation Class | F |
| NEMA Design | B |
| Service Factor | 1.15 |
| Time Rating | Continuous |
| Full Load Efficiency | 87.5 % |
| Full Load Power Factor | 57.0 % |
| Full Load Amps | 7.51 Amps @ 230VAC |
| Shipping Weight | 93 lbs |
Features
- Enclosure: Totally Enclosed Fan Cooled (IP54)
- Voltage: 230/460VAC (Usable on 208VAC)
- Three Phase
60Hz, 1.15 Service Factor
50Hz, 1.00 Service Factor - CSA Certified for Class I, Division 2, Groups B, C & D – Temp Code T3C Minimum
- Class F Insulation
- Class B Temperature Rise
- NEMA Design B Torques
- Cast Iron Frame, End Brackets, Fan Cover and Main Conduit Box
- Grounding Terminal Inside Main Conduit Box
- Oversized Main Conduit Box Rotatable in 90 Degree Increments – F1 Mounted
- Designed for 40°C Ambient Temperature
- Designed for 3300 Feet Elevation
- Bi-Directional Rotation
- 1045 Carbon Steel Shaft
- Aluminum Die Cast Squirrel Cage Rotor Construction
- Paint System: Phenolic Rust Proof Base Plus Polyurethane Top Coat
- Paint Color: Premium – Light Gray – Munsell N5.0
- Double Shielded Ball Bearings Pre-Packed with MULTEMP SRL for Frames 140JP/JM – 280JP/JM (Non-Regreasable)
- Rubber Dust Flinger on DE for Frames 140JP/JM – 280JP/JM
- Stainless Steel Nameplate
Dual Column Design Nameplate as Standard (50/60Hz) - Suitable for Inverter use per NEMA MG-1 Part 31.4.4.2
- Inverter Duty Speed Range: 10:1 Variable Torque, 5:1 Constant Torque
- 9 Leads for 5HP and Smaller
- Motors are UL Recognized, CSA Approved and CE Marked
Applications
- Pumps
