Osram Sylvania 50699-0 Quicktronic Powershed Control Command Injector - Manual/Remote - Universal Line Voltage
COMMAND INJECTOR:
Input Voltage Range: 108-305VAC
Input Voltage Frequency: 50/60 Hz
Input Current: 0.12A @ 120V (12W) / 0.08A @ 277V (13W)
Ambient Temp. Range: -20° to +60°C
Max Case Temp: 70°C (Upper 10-32 screw head on left side of Command Injector case)
FCC: FCC 47 CFR Part 15 Class A (commercial)
POWER LINE CARRIER SIGNAL:
Isolation: Fully isolated
Output Frequency: 21 kHz ± 1kHz
Output Coil Voltage: Up to 12V RMS
Protection: Link to Command Coupler is tolerant of both an open circuit and short circuit
COMMAND COUPLER:
Mounting: Clamped around all panel feeds except Ground
Harness: Cable between Command Coupler and Command Injector is 36" long
SYSTEM
Safety: UL and cUL Listed
