| range |
PowerLogic |
|
|---|---|---|
| product name |
PowerLogic Enercept |
|
| device short name |
Enercept |
|
| product or component type |
Power meter |
|
| device application |
Power monitoring Sub billing |
|
| variant |
Enhanced |
|
| power monitoring |
Basic instrumentation |
|
| type of measurement |
Current Active power Active energy Reactive power Apparent power Power factor total Voltage phase to phase (L-L) Voltage phase to neutral (L-N) Current per phase Power factor per phase |
|
| [Us] rated supply voltage |
208...480 V, AC, 50/60 Hz |
|
| network frequency |
50 Hz 60 Hz |
|
| current transformer type |
Split core balance |
|
|---|---|---|
| analogue input type |
Split core CT, 0…100 A |
|
| measurement voltage |
208...480 V |
|
| measurement accuracy |
+/- 1 % 10...100 % |
|
| communication port protocol |
Modbus RTU |
|
| communication port support |
RS485 |
|
| communication network type |
Modbus RTU |
|
| mounting mode |
Direct |
|
| ambient air temperature for operation |
32...140 °F (0...60 °C) |
|
|---|---|---|
| relative humidity |
95 % |
|
| product certifications |
UL CUL |
|
| width |
1.22 in (31 mm) (internal) 4.76 in (121 mm) (external) |
|
| depth |
1.18 in (30 mm) |
|
| height |
1.18 in (30 mm) (internal) 3.94 in (100 mm) (external) |
|
| product weight |
2.2 lb(US) (1 kg) |
|
| Category |
09791 - POWERLOGIC ENERCEPT POWER METER |
|
|---|---|---|
| Discount Schedule |
PL1 |
|
| GTIN |
00785901380054 |
|
| Nbr. of units in pkg. |
1 |
|
| Package weight(Lbs) |
4 |
|
| Returnability |
N |
|
| Country of origin |
US |
|
