Features
Features
- Two Speed
- Sealed SwitchDesign
- All Copper Windings
- 50°C Ambient
- 304 Bearings Shaft End
- Energy Efficient
- Meets California Energy Commission Appliance Regulations 2008
- UL 1081 Design
- 303 Stainless Steel Shaft
- Threaded Shaft
General Specifications
General Specifications
|
Model : |
STS1152R |
Catalog No : |
STS1152R |
|
Part Description : |
1.5HP 3450/1725 230 ODP 56J THD SHFT 2SP |
Category : |
Induction Motors |
|
Stock : |
Yes |
Nameplate Specifications
Nameplate Specifications
|
Output HP : |
1 1/2,1/4 HP |
Output KW : |
1.1 kW |
|
Frequency : |
60 Hz |
Voltage : |
230 V |
|
Current : |
9.0/3.3 A |
Speed : |
3450/1725 RPM |
|
Service Factor : |
1.3 |
Phase : |
1 |
|
Duty : |
Continuous |
Insulation Class : |
B |
|
Frame : |
56J |
Enclosure : |
Open Drip Proof |
|
Overload Protector : |
Automatic |
Ambient Temperature : |
40 °C |
|
UL : |
Recognized |
CSA : |
Y |
Technical Specifications
Technical Specifications
|
Electrical Type : |
Capacitor Start Capacitor Run |
Poles : |
2/4 |
|
Rotation : |
Counterclockwise Pump End |
Mounting : |
Round |
|
Motor Orientation : |
Horizontal |
Drive End Bearing : |
BALL |
|
Opp Drive End Bearing : |
BALL |
Frame Material : |
Rolled Steel |
|
Shaft Type : |
Threaded |
Overall Length : |
15.63 in |
|
Frame Length : |
9.69 in |
Shaft Diameter : |
0.625 in |
|
Shaft Extension : |
2.568 in |
UPC : |
786674031877 |
|
Weight : |
32.00 LB |
