Features
- Sealed Ball Bearings
- Capacitor Start
- Sealed Switch Design
- 50°C Ambient
- 303 Stainless Shaft
- UL 1081 Design
- 304 Bearing Shaft End
- Threaded Shaft
General Specifications
| UPC: | 786674031778 | Weight: | 21 LB |
| Packaged Length: | 16 IN | Packaged Width: | 9.5 IN |
| Packaged Height: | 9.5 IN |
Nameplate Specifications
| Output HP: | 3/4 Hp | Output KW: | 0.56 kW |
| Frequency: | 60 Hz | Voltage: | 230/115 V |
| Current: | 7.5/15.0 A | Speed: | 3450 rpm |
| Service Factor: | 1.5 | Phase: | 1 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 56J | Enclosure: | Open Drip Proof |
| Thermal Protection: | Automatic | Ambient Temperature: | 50 °C |
| UL: | Recognized | CSA: | Y |
Technical Specifications
| Electrical Type: | Cap Start Motor | Poles: | 2 |
| Rotation: | Counterclockwise Pump End | Mounting: | C Face |
| Motor Orientation: | Horizontal | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Threaded | Overall Length: | 13.53 in |
| Frame Length: | 7.63 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 2.562 in |
