Features
- Sealed Ball Bearings
- Capacitor Start
- Open Dripproof
- 303 Stainless Steel Shaft
- 50°C Ambient
- Energy Efficient
- UL 1081 Design
General Specifications
| UPC: | 786674029331 | Weight: | 31.00 LB |
| Packaged Length: | 16 IN | Packaged Width: | 9.5 IN |
| Packaged Height: | 11 IN |
Nameplate Specifications
| Output HP: | 1 Hp | Output KW: | 0.75 kW |
| Frequency: | 60 Hz | Voltage: | 208-230/115 V |
| Current: | 8.0-8.0/16.0 A | Speed: | 3450 rpm |
| Service Factor: | 1.65 | Phase: | 1 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 48Y | Enclosure: | Open Drip Proof |
| Thermal Protection: | Thermally Protected | Ambient Temperature: | 50 °C |
| UL: | Recognized | CSA: | Y |
Technical Specifications
| Electrical Type: | Capacitor Start Capacitor Run | Poles: | 2 |
| Rotation: | Counterclockwise Pump End | Mounting: | Round |
| Motor Orientation: | Horizontal | Drive End Bearing: | BALL |
| Opp Drive End Bearing: | BALL | Frame Material: | Rolled Steel |
| Shaft Type: | Threaded | Overall Length: | 12.57 in |
| Frame Length: | 8.69 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 0.906 in |
Speed & Load Characteristics
