Features
Features
- Shaft end mechanically locked on C-face models
- Shaft slinger
- Low temperature manual reset thermal protector
- Condensate drains
General Specifications
General Specifications
| Model : | Catalog No : | K311M2 | |
| Part Description : | 7.5,1745,TEFC,215T,1/60/230 | Category : | Single Phase |
| Stock : | Yes |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 7.5 HP | Output KW : | 5.6 kW |
| Frequency : | 60 Hz | Voltage : | 230 V |
| Current : | 34.0 A | Speed : | 1745 RPM |
| Service Factor : | 1 | Phase : | 1 |
| Duty : | Continuous | Insulation Class : | B |
| Frame : | F215T | Enclosure : | Totally Enclosed Fan Cooled |
| Overload Protector : | No | Ambient Temperature : | 40 °C |
| UL : | Recognized | CSA : | Y |
| CE : | N |
Technical Specifications
Technical Specifications
| Electrical Type : | Capacitor Start, Capacitor Run, Single Or Dual Voltage | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Reversible |
| Mounting : | Rigid Base | Drive End Bearing : | Ball |
| Opp Drive End Bearing : | Ball | Frame Material : | Rolled Steel |
| Shaft Type : | Keyed | Overall Length : | 19.12 in |
| Frame Length : | 9.00 in | Shaft Diameter : | 1.375 in |
| Shaft Extension : | 3.50 in | UPC : | 786674069504 |
| Weight : | 150.00 LB |
Speed & Load Characteristics
