Features
Features
- High starting torque
- Removable condensate drain plugs
- Manual reset thermal protector
- All parts are corrosion resistant
General Specifications
General Specifications
| Model : | Catalog No : | K300M2 | |
| Part Description : | 5,1725,TEFC,215TZ,1/60/230 | Category : | Single Phase |
| Stock : | Yes |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 5.0 HP | Output KW : | 3.7 kW |
| Frequency : | 60 Hz | Voltage : | 230 V |
| Current : | 26.0 A | Speed : | 1725 RPM |
| Service Factor : | 1 | Phase : | 1 |
| Duty : | Continuous | Insulation Class : | B |
| Frame : | F215TZ | Enclosure : | Totally Enclosed Fan Cooled |
| Overload Protector : | Manual | Ambient Temperature : | 40 °C |
| UL : | Recognized | CSA : | Y |
| CE : | N |
Technical Specifications
Technical Specifications
| Electrical Type : | Capacitor Start Induction Run | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Reversible |
| Mounting : | Rigid Base | Drive End Bearing : | Ball |
| Opp Drive End Bearing : | Ball | Frame Material : | Aluminium |
| Shaft Type : | Flat | Overall Length : | 19.13 in |
| Frame Length : | 9.00 in | Shaft Diameter : | 1.125 in |
| Shaft Extension : | 3.50 in | UPC : | 786674069436 |
| Weight : | 158.00 LB |
Speed & Load Characteristics
