Features
- Internally mounted capacitor
- Sealed switch design
- Keyed shaft
General Specifications
| UPC: | 786674025524 | Weight: | 16.00 LB |
| Packaged Length: | 16 IN | Packaged Width: | 9.5 IN |
| Packaged Height: | 9.5 IN |
Nameplate Specifications
| Output HP: | 1/3 Hp | Output KW: | 0.25 kW |
| Frequency: | 60 Hz | Voltage: | 230/115 V |
| Current: | 4.3/8.6 A | Speed: | 3450 rpm |
| Service Factor: | 1.8 | Phase: | 1 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 56C | Enclosure: | Open Drip Proof |
| Thermal Protection: | Automatic | Ambient Temperature: | 40 °C |
| UL: | Recognized | CSA: | Y |
| CE: | N |
Technical Specifications
| Electrical Type: | Capacitor Start Induction Run | Starting Method: | Across The Line |
| Poles: | 2 | Rotation: | Reversible |
| Mounting: | Round | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Keyed | Overall Length: | 10.31 in |
| Frame Length: | 5.00 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 2.06 in |
