Features
- Double sealed ball bearings, mechanically locked on shaft end
- Drip cover not included, see Accessories Section
- 56J = 416 stainless steel threaded shaft with slinger
- Automatic reset thermal protector
- 56C = carbon steel shaft with key
General Specifications
| UPC: | 722856048875 | Weight: | 16.00 LB |
| Packaged Length: | 13.69 IN | Packaged Width: | 7.13 IN |
| Packaged Height: | 7.5 IN |
Nameplate Specifications
| Output HP: | 1/3 Hp | Output KW: | 0.25 kW |
| Frequency: | 60 Hz | Voltage: | 115/230 V |
| Current: | 6.4,3.2 A | Speed: | 3450 rpm |
| Service Factor: | 1.75 | Phase: | 1 |
| Efficiency: | 56.6 % | Power Factor: | 0 |
| Duty: | Continuous | Insulation Class: | B |
| KVA Code: | L | Frame: | 56C |
| Enclosure: | Drip Proof | Thermal Protection: | AUTO |
| Ambient Temperature: | 40 °C | Drive End Bearing Size: | 6203 |
| Opp Drive End Bearing Size: | 6203 | UL: | Recognized |
| CSA: | Yes | CE: | N |
Technical Specifications
| Electrical Type: | Capacitor Start Induction Run | Starting Method: | SM |
| Poles: | 2 | Rotation: | Clockwise/Counterclockwise |
| Mounting: | Round | Motor Orientation: | ANY |
| Drive End Bearing: | LOCKED | Opp Drive End Bearing: | BALL |
| Frame Material: | Rolled Steel | Overall Length: | 10.71 in |
| Frame Length: | 6.62 in | Shaft Diameter: | 0.63 in |
| Shaft Extension: | 1.88 in | Thru-bolts Extension: | 0 in |
Speed & Load Characteristics
