Features
- Automatic reset thermal protector
General Specifications
| UPC: | 786674025296 | Weight: | 15.00 LB |
| Packaged Length: | 11 IN | Packaged Width: | 8 IN |
| Packaged Height: | 9 IN |
Nameplate Specifications
| Output HP: | 1/6 Hp | Output KW: | 0.13 kW |
| Frequency: | 60 Hz | Voltage: | 115 V |
| Current: | 3.5 A | Speed: | 1725 rpm |
| Service Factor: | 1.75 | Phase: | 1 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 48Z | Enclosure: | Open Drip Proof |
| Thermal Protection: | Automatic | Ambient Temperature: | 50 °C |
| UL: | Recognized | CSA: | Y |
| CE: | N |
Technical Specifications
| Electrical Type: | Split Phase | Starting Method: | Across The Line |
| Poles: | 4 | Rotation: | Counterclockwise |
| Mounting: | Resilient Base | Drive End Bearing: | Sleeve |
| Opp Drive End Bearing: | Sleeve | Frame Material: | Rolled Steel |
| Shaft Type: | Spot Drill | Overall Length: | 8.29 in |
| Frame Length: | 4.34 in | Shaft Diameter: | 0.500 in |
| Shaft Extension: | 0.83 in |
