Electrical
| HP | 1/25 HP |
|---|---|
| Voltage | 115/230 VAC |
| Frequency | 60 Hz |
| Phase | Single Phase |
| RPM | 1550 RPM Single Speed |
| Amperage | 0.75-0.4 Amps |
Specifications
| Manufacturer | Fasco |
|---|---|
| Model Number | D1164 |
| Diameter | 3.3 inches |
| Rotation Direction | CW |
| Bearing Type | Sleeve |
| Shaft Dimensions | 5/16" x 2-1/2" |
| Stack | inches |
| Notes | 85: Air Over |
| Weight | 3.8 lbs |
| Frame | |
| Type | |
| Enclosure | Totally Enclosed |
| ”A” Dimension | 3-1/8" |
Cross Reference
| Singer | JA2P091N JA2P0901N |
|---|
