Features
- 5/8” keyed shaft
- "Quick connect" terminal board
General Specifications
| Model : | Catalog No : | OL1072D | |
| Part Description : | 3/4,3450,OPEN,48CZ,1/60/115/208-230 | Category : | Oil Burner |
| Stock : | Yes |
Nameplate Specifications
| Output HP : | 3/4 Hp | Output KW : | 0.56 kW |
| Frequency : | 60 Hz | Voltage : | 115/208-230 V |
| Current : | 10.0/5.0 A | Speed : | 3450 rpm |
| Service Factor : | 1 | Phase : | 1 |
| Duty : | Continuous | Insulation Class : | B |
| Frame : | 48CZ | Enclosure : | Open Enclosed |
| Overload Protector : | Manual | Ambient Temperature : | 40 °C |
| UL : | No | CSA : | Y |
| CE : | N |
Technical Specifications
| Electrical Type : | Capacitor Start Induction Run | Starting Method : | Across The Line |
| Poles : | 2 | Rotation : | Reversible |
| Mounting : | C | Drive End Bearing : | Ball |
| Opp Drive End Bearing : | Ball | Frame Material : | Rolled Steel |
| Shaft Type : | Keyed | Overall Length : | 10.81 in |
| Frame Length : | 5.94 in | Shaft Diameter : | 0.625 in |
| Shaft Extension : | 2.06 in | UPC : | 786674027801 |
| Weight : | 20.00 LB |
