Features
- Sleeve bearing
- "Quick connect" terminal board
General Specifications
| Model : | Catalog No : | OL1032D | |
| Part Description : | 1/3,3450,ODP,48N,1/60/115/230 | Category : | Oil Burner |
| Stock : | Yes |
Nameplate Specifications
| Output HP : | 1/3 Hp | Output KW : | 0.25 kW |
| Frequency : | 60 Hz | Voltage : | 115/230 V |
| Current : | 4.2/2.1 A | Speed : | 3450 rpm |
| Service Factor : | 1.35 | Phase : | 1 |
| Duty : | Continuous | Insulation Class : | B |
| Frame : | 48N | Enclosure : | Open Drip Proof |
| Overload Protector : | Manual | Ambient Temperature : | 40 °C |
| UL : | Recognized | CSA : | Y |
| CE : | N |
Technical Specifications
| Electrical Type : | Capacitor Start Induction Run | Starting Method : | Across The Line |
| Poles : | 2 | Rotation : | Reversible |
| Mounting : | N | Drive End Bearing : | Sleeve |
| Opp Drive End Bearing : | Sleeve | Frame Material : | Rolled Steel |
| Shaft Type : | Flat | Overall Length : | 11.91 in |
| Frame Length : | 6.44 in | Shaft Diameter : | 0.500 in |
| Shaft Extension : | 2 in | UPC : | 786674027788 |
| Weight : | 20.00 LB |
