Features
- Heavy gauge steel frame and base
General Specifications
| UPC: | 786674073761 | Weight: | 46.00 LB |
| Packaged Length: | 15.5 IN | Packaged Width: | 10.5 IN |
| Packaged Height: | 10 IN |
Nameplate Specifications
| Output HP: | 1.5 Hp | Output KW: | 1.1 kW |
| Frequency: | 60 Hz | Voltage: | 115/230 V |
| Current: | 12.6/6.3 A | Speed: | 1725 rpm |
| Service Factor: | 1.15 | Phase: | 1 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 56HC | Enclosure: | Drip Proof |
| Thermal Protection: | Thermally Protected | Ambient Temperature: | 40 °C |
| UL: | Recognized | CSA: | Y |
| CE: | Y |
Technical Specifications
| Electrical Type: | Shaded Pole | Starting Method: | Across The Line |
| Poles: | 4 | Rotation: | Selective Counterclockwise |
| Mounting: | Rigid Base | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | NEMA 56 | Overall Length: | 13.81 in |
| Frame Length: | 9.74 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 1.88 in |
Speed & Load Characteristics
