BR0675 Century C-Frame / Skeleton Electric Motor, 7/8" STACK HP

$40.97 USD

Shipping calculated at checkout

Century Electric Motor (Regal Rexnord) SKU: BR0675 Barcode: 786674014504

30 Day
Return Policy

Ships Fast
in 24 hours

120VAC Single Phase 60Hz, 2850RPM, Continuous Air Over

Description Product Specs Manufacturer





Features




Features


  • OEM Direct Replacement Motor

  • C-Frame

  • Shaded Pole

  • Thermally Protected

  • Open Air Over

  • Class B Insulation, 40°C Ambient

  • Sleeve Bearing

  • .217" Diameter Shaft with Flat

  • 6.9" Leads with Molded Plug

  • Extended Studs Opposite Lead End






General Specifications





General Specifications






























Model :

Catalog No :
BR0675

Part Description :
MODEL-SFHP-C-FR
Category :
C-Frame / Skeleton

Stock :
Yes






Nameplate Specifications





Nameplate Specifications























































Output HP :
7/8" STACK
Frequency :
60 Hz

Voltage :
120 V
Current :
1.4 A

Speed :
2850 RPM
Service Factor :
1

Phase :
1
Duty :
Continuous Air Over

Insulation Class :
B
Frame :
C-FRAME

Enclosure :
Open Air Over
Overload Protector :
Automatic

Ambient Temperature :
40 °C
UL :
Recognized

CSA :
Y
CE :
N






Technical Specifications





Technical Specifications















































Electrical Type :
Shaded Pole
Starting Method :
Induction Run

Poles :
2
Rotation :
Counterclockwise

Mounting :
Bracket
Drive End Bearing :
Sleeve

Opp Drive End Bearing :
Sleeve
Frame Material :
Na

Shaft Type :
Flat
Shaft Diameter :
0.217 in

Shaft Extension :
1.2 in
UPC :
786674014504

Weight :
2.00 LB






Speed & Load Characteristics








  • Electric Motor
  • Single Phase
  • 2850RPM

Century Electric Motor (Regal Rexnord)
