Features
- Two Speed
- 12 & 3 O'clock Conduit Entries
- 3-1/2" Shaft Height
- 50°C Ambient
- Four Thru Bolts on a 5.146 Bolt Circle
- Flex 48 LASAR XL for Extra Low Running Amps with 48/56 Base Mounting
- Threaded Shaft
- Rigid Base
- Energy Efficient
- Meets California Energy Commission Appliance Regulations 2008
General Specifications
| UPC: | 786674014481 | Weight: | 33.00 LB |
| Packaged Length: | 16 IN | Packaged Width: | 9.5 IN |
| Packaged Height: | 11 IN |
Nameplate Specifications
| Output HP: | 4.0-.42 Hp | Output KW: | 3.0 kW |
| Frequency: | 60 Hz | Voltage: | 208-230 V |
| Current: | 12.0/3.5 A | Speed: | 3450/1725 rpm |
| Service Factor: | 1 | Phase: | 1 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | Y48Y | Enclosure: | Drip Proof |
| Thermal Protection: | Thermally Protected | Ambient Temperature: | 50 °C |
| UL: | Recognized | CSA: | Y |
Technical Specifications
| Electrical Type: | Permanent Split Capacitor, High Speed; Capacitor Start, Low Speed | Poles: | 2/4 |
| Rotation: | Counterclockwise Pump End | Mounting: | Thru Bolt |
| Motor Orientation: | Horizontal | Drive End Bearing: | BALL |
| Opp Drive End Bearing: | BALL | Frame Material: | Rolled Steel |
| Shaft Type: | Threaded | Overall Length: | 14.33 in |
| Frame Length: | 9.50 in | Shaft Diameter: | 0.500 in |
| Shaft Extension: | 2.36 in |
Speed & Load Characteristics
