Features
Features
- Furnace Blower - Air Handler - Fan Coil - Air Conditioning Motor
- 5" Diameter - 42 Frame
- Permanent Split Capacitor
- Thermally Protected
- Open Shaft End End-Frame and Shaft End Shell, Lead End End-Frame Half Open and Lead End Shell Half Open, Air Over
- Class B Insulation, 40°C Ambient
- Sleeve Bearing
- 1/2" Diameter Shaft with Flat
- 28" Leads
- Extended Studs Shaft End, Resilient Ring Mounting, Belly Band
General Specifications
General Specifications
| Model : | Catalog No : | BL6519 | |
| Part Description : | MODEL-RFHP-42FR | Category : | Direct Drive |
| Stock : | Yes |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 1/4 1/5 1/6 Hp | Frequency : | 60 Hz |
| Voltage : | 115 V | Current : | 4.7 A |
| Speed : | 1075 rpm | Service Factor : | 1 |
| Phase : | 1 | Duty : | Air Over |
| Insulation Class : | B | Frame : | 42Y |
| Enclosure : | Open Air Over | Overload Protector : | Automatic |
| Ambient Temperature : | 40 °C | UL : | Recognized |
| CSA : | Y | CE : | N |
Technical Specifications
Technical Specifications
| Electrical Type : | Permanent Split Capacitor | Starting Method : | Induction Run |
| Poles : | 6 | Rotation : | Reversible |
| Mounting : | Extended Studs | Motor Orientation : | Horizontal |
| Drive End Bearing : | Sleeve | Opp Drive End Bearing : | Sleeve |
| Frame Material : | Rolled Steel | Shaft Type : | Flat |
| Overall Length : | 9.83 in | Shaft Diameter : | 0.500 in |
| Shaft Extension : | 4.7 in | UPC : | 786674014160 |
| Weight : | 11.00 LB |
