Specifications
| Seal Size | 5/8" 0.625" |
|---|---|
| Head Figure | A |
| Head Outside Diameter | 1.218" |
| Head Operating Height | 0.718" |
| Mating Ring Figure | 1 |
| Mating Ring Bore | 1.250" |
| Mating Ring Thickness | 0.406" |
| Material Code | VCFJF
Viton Secondary Seals Carbon Primary Rings Stainless Steel Metal Parts Ceramic Mating Rings Stainless Steel Springs |
| Notes | |
| UPC | |
| Weight | 0.20 lbs |
| Pressure Rating | PSI |
| Temperature | °F to °F |
| Country of Origin | Mexico |
| U.S. Seal Mfg Cross Reference |
Cross Reference
| Manufacturer | Pump Nameplate Data | Mfg Part Number |
|---|---|---|
| American Machine and Tool Company | 1640-161-91 | |
| Carver Pump Company | 091-062-02-2322 | |
| Crane-Deming | 0040861 | |
| Delavan Pumps, Inc. | 34943 | |
| Frankline Electric Company | 240316, 106196106 | |
| Gecko Alliance, Inc. | 92500152 | |
| Grundfos, Inc. | 98833732 | |
| Hydromatic Pump Company | 830101 | |
| Hypro Corporation | 9203, 9401C, 9300CHM | 2120-0009 |
| Monarch Pumps | ATH, AT600 | 240136 |
| F.E. Myers | 21181A044 | |
| Scot Pump | 101.000.110B | |
| Shippensburg Pump Co., Inc. | SDPS-00067V | |
| Sid Harvey Industries | 0369 | |
| Sta-Rite Industries | 21181A044 | |
| Toro Company | 42088 | |
| Waterway Plastics | EX2, Hi-Flo II, Supreme, Viper | 319-3010B |
| Weber Industries, Inc. | 70X103-M |
