Features
- Capacitor start / capacitor run design for low amps and high efficiency
- High starting and breakdown torque
- Heavy gauge steel frame and base
- Continuous duty at nameplate ratings
- Connected for CW rotation facing opposite shaft end. Reversible by reconnection of leads
- Energy saver design
General Specifications
| UPC: | 722856048226 | Weight: | 38.00 LB |
Nameplate Specifications
| Output HP: | 2 Hp | Output KW: | 1.5 kW |
| Frequency: | 60 Hz | Voltage: | 115/230 V |
| Current: | 15.0,7.5 A | Speed: | 3450 rpm |
| Service Factor: | 1 | Phase: | 1 |
| Efficiency: | 79.1 % | Power Factor: | 0 |
| Duty: | Continuous | Insulation Class: | B |
| KVA Code: | G | Frame: | 56 |
| Enclosure: | Drip Proof | Thermal Protection: | MAN |
| Ambient Temperature: | 40 °C | Drive End Bearing Size: | 6203 |
| Opp Drive End Bearing Size: | 6203 | UL: | Recognized |
| CSA: | Yes | CE: | N |
Technical Specifications
| Electrical Type: | Capacitor Start Capacitor Run | Starting Method: | SM |
| Poles: | 2 | Rotation: | Clockwise/Counterclockwise |
| Mounting: | Rigid Base | Motor Orientation: | ANY |
| Drive End Bearing: | BALL | Opp Drive End Bearing: | BALL |
| Frame Material: | Rolled Steel | Overall Length: | 12.76 in |
| Frame Length: | 8.43 in | Shaft Diameter: | 0.63 in |
| Shaft Extension: | 1.88 in |
