Features
- UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
- Premium efficiency promotes improved reliability.
- Heavy-duty, rolled steel construction ensures motor durability.
- Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
General Specifications
| UPC: | 722856007025 | Weight: | 19.00 LB |
| Packaged Length: | 12.63 IN | Packaged Width: | 6.94 IN |
| Packaged Height: | 7.5 IN | HTC: | 8501.40.4040 |
| Country of Origin: | Mexico | ||
Nameplate Specifications
Nameplate Specifications
| Output HP: | 0.75 Hp | Output KW: | 0.56 kW |
| Frequency: | 60 Hz | Voltage: | 115/230 V |
| Current: | 11.2,5.6 A | Speed: | 3450 rpm |
| Service Factor: | 1 | Phase: | 1 |
| Efficiency: | 66 % | Power Factor: | 0 |
| Duty: | Continuous | Insulation Class: | B |
| KVA Code: | J | Frame: | 48 |
| Enclosure: | Drip Proof | Thermal Protection: | No Protection |
| Ambient Temperature: | 40 °C | Drive End Bearing Size: | 6203 |
| Opp Drive End Bearing Size: | 6203 | UL: | Recognized |
| CSA: | Yes | CE: | N |
| Number of Speeds: | 1 |
Technical Specifications
| Electrical Type: | Capacitor Start Induction Run | Starting Method: | SM |
| Poles: | 2 | Rotation: | Counterclockwise/Clockwise |
| Mounting: | Rigid Base | Motor Orientation: | ANY |
| Drive End Bearing: | BALL | Opp Drive End Bearing: | Ball |
| Frame Material: | Rolled Steel | Overall Length: | 10.06 in |
| Frame Length: | 6.62 in | Shaft Diameter: | 0.500 in |
| Shaft Extension: | 1.5 in |
