Features
Features
- Rugged die cast aluminum gear housing for maximum gear and bearing support
- Precision machined gearing, hardened for maximum load capability
- All gearing designed and rated to AGMA class 9 standards, and to withstand momentary shock overload of 200%
- Oversized output bearings for greater overhung load capacity and long life
- High carbon alloy output shaft provides maximum strength and rigidity
- All needle bearing journals are precision ground after heat treating to provide maximum fit and finish
- Heavy duty industrial oil seals keep lubricant in and dirt out
- Gears and bearings are splash lubricated with permanent, heavy duty gear oil
- Conduit box included as standard
General Specifications
General Specifications
|
Model : |
C4T17FZ47B |
Catalog No : |
107025.00 |
|
Part Description : |
P1100...95:1.18RPM.1089LBIN..33HP.48Y...AC GEARMOTORS FHP.208-230/460V.3PH.60HZ.TEFC.C4T17FZ47B |
Category : |
P1100 Series |
|
Stock : |
No |
Nameplate Specifications
Nameplate Specifications
|
Output HP : |
0.33 HP |
Output KW : |
0.25 kW |
|
Frequency : |
60 Hz |
Voltage : |
208-230/460 V |
|
Current : |
1.6/0.80 A |
Speed : |
18 RPM |
|
Service Factor : |
1.15 |
Phase : |
3 |
|
Duty : |
Continuous |
Insulation Class : |
F |
|
KVA Code : |
L |
Frame : |
48Y |
|
Enclosure : |
Totally Enclosed Fan Cooled |
Overload Protector : |
No |
|
Ambient Temperature : |
40 °C |
Drive End Bearing Size : |
6203 |
|
Opp Drive End Bearing Size : |
6203 |
UL : |
Recognized |
|
CSA : |
Y |
CE : |
N |
Technical Specifications
Technical Specifications
|
Rotation : |
Reversible |
Mounting : |
Special |
|
Shaft Type : |
Parallel |
Overall Length : |
12.92 in |
|
Frame Length : |
5.00 in |
Shaft Diameter : |
0.750 in |
|
Shaft Extension : |
1.5 in |
UPC : |
691720006467 |
|
Weight : |
34.00 LB |
Speed & Load Characteristics
