Features
- 1" longer shaft than NEMA standard
- Shaft seals both ends
- Premium efficient
- Epoxy Painted
- Normally closed T-stats
- Cast iron construction
General Specifications
| Model : | C182T17FK49A | Catalog No : | 171845.60 |
| Part Description : | ..3HP..1800RPM.182TZ.TEFC.230/460V.3PH.60HZ.CONT.40C.1.15SF.RIGID......GRAIN DRYER........ | Category : | Grain Stirring |
| Stock : | No |
Nameplate Specifications
| Output HP : | 3 Hp | Output KW : | 2.2 kW |
| Frequency : | 60 Hz | Voltage : | 208-230/460 V |
| Current : | 8.3-7.8/3.9 A | Speed : | 1770 rpm |
| Service Factor : | 1.15 | Phase : | 3 |
| Efficiency : | 89.5 % | Duty : | Continuous |
| Insulation Class : | F | Design Code : | B |
| KVA Code : | J | Frame : | 182TZ |
| Enclosure : | Totally Enclosed Fan Cooled | Overload Protector : | No |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6206 |
| Opp Drive End Bearing Size : | 6205 | UL : | Recognized |
| CSA : | Y | CE : | Y |
| IP Code : | 55 |
Technical Specifications
| Electrical Type : | Squirrel Cage Inverter Rated | Starting Method : | Line Or Inverter |
| Poles : | 4 | Rotation : | Reversible |
| Mounting : | Rigid base | Motor Orientation : | Horizontal |
| Drive End Bearing : | Ball | Opp Drive End Bearing : | Ball |
| Frame Material : | Cast Iron | Shaft Type : | Single Special Extension |
| Overall Length : | 17.10 in | Shaft Diameter : | 1.125 in |
| Shaft Extension : | 3.755 in | Assembly/Box Mounting : | F1/F2 CAPABLE |
| UPC : | 691720053607 | Weight : | 113.00 LB |
