Features
Features
- Shaft end mechanically locked on C-face models
- Capacitor start design for high starting torque
- Shaft slinger
- Low temperature manual reset thermal protector
- Totally enclosed and fully gasketed construction for dirty environments
- Condensate drains
General Specifications
General Specifications
| Model : | 056C17F5326 | Catalog No : | F103 |
| Part Description : | 3/4,1800,TEFC,56,1/60/115/208-230 | Category : | Single Phase |
| Stock : | Yes |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 0.75 Hp | Output KW : | 0.56 kW |
| Frequency : | 60 Hz | Voltage : | 115/208-230 V |
| Current : | 11.0/5.4-5.5 A | Speed : | 1725 rpm |
| Service Factor : | 1.15 | Phase : | 1 |
| Efficiency : | 70.5 % | Duty : | Continous |
| Insulation Class : | B | Design Code : | L |
| KVA Code : | L | Frame : | 56 |
| Enclosure : | Totally Enclosed Fan Cooled | Overload Protector : | Manual |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6203 |
| Opp Drive End Bearing Size : | 6203 | UL : | Recognized |
| CSA : | Y | CE : | N |
| IP Code : | 43 |
Technical Specifications
Technical Specifications
| Electrical Type : | Capacitor Start Induction Run | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Selective Counterclockwise |
| Mounting : | Rigid Base | Motor Orientation : | Horizontal |
| Drive End Bearing : | Ball | Opp Drive End Bearing : | Ball |
| Frame Material : | Rolled Steel | Shaft Type : | T |
| Overall Length : | 12.32 in | Frame Length : | 7.06 in |
| Shaft Diameter : | 0.625 in | Shaft Extension : | 2.32 in |
| Assembly/Box Mounting : | F1 Only | UPC : | 722856027771 |
| Weight : | 29.00 LB |
Speed & Load Characteristics
