| Rated insulation voltage Ui (pollution degree 3) - IEC 60974-4-1 | 1000 V |
|---|---|
| Rated insulation voltage Ui (pollution degree 3) - UL, CSA | 600 V |
| Rated operational frequency - minimum | 25 Hz |
| Rated operational frequency - maximum | 400 Hz |
| MECHANICAL LIFESPAN AC | 10 million |
| MECHANICAL LIFESPAN DC | 12 million |
| Electrical lifespan | 1,2 million |
| Degree of protection IP (IEC 60529) - Main circuit | IP10 |
| Degree of protection IP (IEC 60529) - Control circuit | IP20 |
| Rated current In - AC-3 (Ue = 440 V) | 18 A |
|---|---|
| Rated current In - AC-4 | 8 A |
| Rated operational Current Ie AC-1 (¿ = 55 ºC) | 32 A |
| Rated operational voltage Ue - IEC 60947-4-1 | 690 V |
| Rated operational voltage Ue - UL/CSA | 600 V |
| Height | 81 mm (3.19 in) |
| Width | 45 mm (1.77 in) |
| Depth | 87 mm (3.43 in) |
| Gross weight | 300 g |
