Features
- Stainless steel frame, base, capacitor case and conduit box cover
- 15 minute duty cycle
- Drain holes located at 6:00 position
- TENV enclosure
- Die cast Aluminum end bells
- Capacitor case located at 12:00
- 115/230 Volt – 1.15 S.F.
- UL recognized component listing and CSA approved
General Specifications
| Model : | C6K17NC19 A | Catalog No : | 6439191264 |
| Part Description : | 2HP..1800RPM.56C.TENV.115/230V.1PH.60HZ.15 MIN.NOT.40C.1.15SF.C-FACE.BOAT HOIST. | Category : | Boat Hoist Duty |
| Stock : | No |
Nameplate Specifications
| Output HP : | 2 Hp | Output KW : | 1.5 kW |
| Frequency : | 60 Hz | Voltage : | 115/230 V |
| Current : | 18.0/9.0 A | Speed : | 1725 rpm |
| Service Factor : | 1.15 | Phase : | 1 |
| Efficiency : | 76 % | Duty : | 15 Minute |
| Insulation Class : | B | Design Code : | N |
| KVA Code : | J | Frame : | 56C |
| Enclosure : | Totally Enclosed Non Ventilated | Overload Protector : | No |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6203 |
| Opp Drive End Bearing Size : | 6203 | UL : | Recognized |
| CSA : | Y | CE : | Y |
| IP Code : | 43 |
Technical Specifications
| Electrical Type : | Capacitor Start Capacitor Run | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Selective Counterclockwise |
| Mounting : | Round | Motor Orientation : | HORIZONTAL |
| Drive End Bearing : | BALL | Opp Drive End Bearing : | BALL |
| Frame Material : | Stainless Steel | Shaft Type : | T |
| Overall Length : | 13.40 in | Frame Length : | 7.68 in |
| Shaft Diameter : | 0.625 in | Shaft Extension : | 1.88 in |
| Assembly/Box Mounting : | F1 ONLY | UPC : | 691720000106 |
| Weight : | 45.00 LB |
Speed Characteristics
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | Torque (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Pull-Up | 0.00 | 0.0 | 180.50 | 188.0 | 1,343 | 0.00 | 0.0 | 2.00 |
| Full Load | 8.77 | 100.0 | 95.80 | 100.0 | 1,754 | 1.77 | 0.0 | 2.00 |
| Break-Down | 0.00 | 0.0 | 270.20 | 282.0 | 1,521 | 0.00 | 0.0 | 2.00 |
| Locked-Rotor | 69.30 | 790.0 | 220.60 | 230.0 | 0 | 11.60 | 0.0 | 2.00 |
Load Characteristics
- % of Rated Load
- Current (Amps)
- Rated Output (KW)
- Efficiency (%)
- Power Factor (%)
- Speed (RPM)
- Temp. Rise @ FL
- Torque (ft-lb)
- 0 %
- 3.98
- 0.222
- 7.2
- 24.3
- 1,799
- 0.0
- 1.00
- 25 %
- 4.46
- 0.570
- 65.4
- 55.6
- 1,788
- 0.0
- 23.50
- 50 %
- 5.58
- 0.948
- 78.8
- 73.9
- 1,778
- 0.0
- 47.30
- 75 %
- 7.05
- 1.344
- 83.2
- 82.9
- 1,767
- 0.0
- 71.30
- 100 %
- 8.77
- 1.765
- 84.5
- 87.5
- 1,754
- 0.0
- 95.80
- 115 %
- 9.91
- 2.030
- 84.5
- 89.1
- 1,746
- 0.0
- 110.70
- 125 %
- 10.71
- 2.210
- 84.4
- 89.7
- 1,740
- 0.0
- 120.70
- 150 %
- 12.86
- 2.690
- 83.2
- 90.9
- 1,726
- 0.0
- 146.10
