Features
- Rugged die cast aluminum gear housing for maximum gear and bearing support
- Precision machined gearing, hardened for maximum load capability
- All gearing designed and rated to AGMA class 9 standards, and to withstand momentary shock overload of 200%
- Oversized output bearings for greater overhung load capacity and long life
- High carbon alloy output shaft provides maximum strength and rigidity
- All needle bearing journals are precision ground after heat treating to provide maximum fit and finish
- Heavy duty industrial oil seals keep lubricant in and dirt out
- Gears and bearings are splash lubricated with permanent, heavy duty gear oil
- Optional conduit box available
General Specifications
| UPC: | 691720091838 | Weight: | 12.00 LB |
| Packaged Length: | 16.5 IN | Packaged Width: | 7.68 IN |
| Packaged Height: | 6.69 IN |
Nameplate Specifications
| Output HP: | 0.13 Hp | Output KW: | 0.10 kW |
| Voltage: | 90 V | Current: | 1.0 A |
| Speed: | 14 rpm | Service Factor: | 1 |
| Efficiency: | 47.2 % | Duty: | Continuous |
| Insulation Class: | F | Frame: | 34 |
| Enclosure: | Totally Enclosed Non Ventilated | Thermal Protection: | No |
| Ambient Temperature: | 40 °C | Drive End Bearing Size: | 6201 |
| Opp Drive End Bearing Size: | 608 | UL: | Recognized |
| CSA: | Y | CE: | Y |
Technical Specifications
| Rotation: | Reversible | Mounting: | Special |
| Shaft Type: | Parallel | Overall Length: | 11.31 in |
| Frame Length: | 4.06 in | Shaft Diameter: | 0.750 in |
| Shaft Extension: | 1.625 in |
Speed & Load Characteristics
