Features
Features
- Compact, space saving design
- Standard conduit box simplifies connections
- Ball bearing construction; Long life brushes
- External access to brushes allows for easy replacement further prolonging motor life
- High starting torques
- Linear speed torque characteristics throughout the speed range
- Capable of dynamic braking for faster stops
- Reversible rotation
- Simple two lead connection
- Class F insulated with high temperature welded commutators
General Specifications
General Specifications
| Model : | CM31D17NZ26D | Catalog No : | M1120046.00 |
| Part Description : | ..1/6HP-1/3HP..1800RPM - 3900RPM.31.TENV.12V - 24V...CONT.40C.1.0SF.SQ. FLANGE.CM31D17NZ26D.....DC SUB-FHP LOW VOLTAGE........ | Category : | Sub-Fractional |
| Stock : | No |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 0.17-0.33 Hp | Output KW : | 0.13-0.25 kW |
| Voltage : | 12-24 V | Current : | 14.0 A |
| Speed : | 1800-3900 rpm | Service Factor : | 1 |
| Efficiency : | 72.8 % | Duty : | Continuous |
| Insulation Class : | F | Frame : | 31 |
| Enclosure : | Totally Enclosed Non Ventilated | Overload Protector : | No |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6201-13 |
| Opp Drive End Bearing Size : | 6201-13 | UL : | Recognized |
| CSA : | Y | CE : | Y |
Technical Specifications
Technical Specifications
| Rotation : | Reversible | Mounting : | Round |
| Overall Length : | 9.45 in | Frame Length : | 5.50 in |
| Shaft Diameter : | 0.500 in | Shaft Extension : | 1.5 in |
| UPC : | 691720090848 | Weight : | 9.00 LB |
