Features
- 1" longer shaft than NEMA standard
- Shaft seals both ends
- Premium efficient
- Epoxy Painted
- Normally closed T-stats
- Cast iron construction
General Specifications
| Model : | C213T17FK48A | Catalog No : | 171847.60 |
| Part Description : | ..7.5HP..1800RPM.213TZ.TEFC.230/460V.3PH.60HZ.CONT.40C.1.15SF.RIGID......GRAIN DRYER........ | Category : | Grain Stirring |
| Stock : | No |
Nameplate Specifications
| Output HP : | 7.50 Hp | Output KW : | 5.6 kW |
| Frequency : | 60 Hz | Voltage : | 208-230/460 V |
| Current : | 20.0-18.6/9.3 A | Speed : | 1770 rpm |
| Service Factor : | 1.15 | Phase : | 3 |
| Efficiency : | 91.7 % | Duty : | Continuous |
| Insulation Class : | F | Design Code : | A |
| KVA Code : | J | Frame : | 213TZ |
| Enclosure : | Totally Enclosed Fan Cooled | Overload Protector : | No |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6308 |
| Opp Drive End Bearing Size : | 6306 | UL : | Recognized |
| CSA : | Y | CE : | Y |
| IP Code : | 55 |
Technical Specifications
| Electrical Type : | Squirrel Cage Inverter Rated | Starting Method : | Line Or Inverter |
| Poles : | 4 | Rotation : | Reversible |
| Mounting : | Rigid base | Motor Orientation : | Horizontal |
| Drive End Bearing : | Ball | Opp Drive End Bearing : | Ball |
| Frame Material : | Cast Iron | Shaft Type : | Single Special Extension |
| Overall Length : | 19.37 in | Shaft Diameter : | 1.375 in |
| Shaft Extension : | 4.38 in | Assembly/Box Mounting : | F1/F2 CAPABLE |
| UPC : | 691720053621 | Weight : | 156.00 LB |
Speed Characteristics
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | Torque (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Locked-Rotor | 74.50 | 793.0 | 49.50 | 220.0 | 0 | 35.0 | 7.50 | |
| Break-Down | 48.50 | 516.0 | 81.00 | 360.0 | 1,550 | 68.0 | 7.50 | |
| No Load | 4.45 | 47.0 | 0.00 | 0.0 | 1,800 | 5.8 | 7.50 | |
| Pull-Up | 71.00 | 755.0 | 42.00 | 187.0 | 900 | 7.50 | ||
| Full Load | 9.40 | 100.0 | 22.50 | 100.0 | 1,770 | 82.0 | 7.50 |
Load Characteristics
- % of Rated Load
- Current (Amps)
- Rated Output (KW)
- Efficiency (%)
- Power Factor (%)
- Speed (RPM)
- Temp. Rise @ FL
- Torque (ft-lb)
- 0 %
- 4.45
- 0.209
- 0.0
- 5.8
- 1,800
- 0.0
- 0.00
- 25 %
- 4.85
- 1.647
- 85.5
- 42.6
- 1,793
- 0.0
- 5.53
- 50 %
- 6.04
- 3.136
- 90.2
- 65.2
- 1,786
- 0.0
- 11.20
- 75 %
- 7.62
- 4.645
- 91.7
- 76.5
- 1,778
- 0.0
- 16.83
- 100 %
- 9.30
- 6.155
- 91.7
- 82.3
- 1,770
- 35.0
- 22.50
- 115 %
- 11.20
- 7.050
- 91.7
- 83.5
- 1,765
- 45.0
- 25.90
- 125 %
- 12.00
- 7.675
- 91.6
- 84.9
- 1,761
- 0.0
- 28.10
- 150 %
- 13.52
- 9.290
- 90.3
- 86.2
- 1,751
- 0.0
- 33.70
