Features
- USDA-approved epoxy painted motors
- NEMA motors
- Rigid base and C face mount types
- BISSC approved designs; Double lip contact seals and v-ring seals used for shaft seals
- 3-year warranty on encapsulated and premium efficient models
- UL recognized and CSA certified
- Double lip contact seals and v-ring seals used for shaft seals
- 3-year warranty on encapsulated and premium efficient models
- Washdown brakemotors and pump motors available
General Specifications
| Model : | C182T17WC13A | Catalog No : | 132439.00 |
| Part Description : | ..3HP..1800RPM.182TC.TEFC.230/460V.3PH.60HZ.CONT.40C.1.15 S.F..C FACE......WASHDOWN DUTY........ | Category : | General Purpose |
| Stock : | No |
Nameplate Specifications
| Output HP : | 3 Hp | Output KW : | 2.2 kW |
| Frequency : | 60 Hz | Voltage : | 208-230/460 V |
| Current : | 8.4-7.8/3.9 A | Speed : | 1770 rpm |
| Service Factor : | 1.15 | Phase : | 3 |
| Efficiency : | 89.5 % | Duty : | Continuous |
| Insulation Class : | F | Design Code : | B |
| KVA Code : | K | Frame : | 182TC |
| Enclosure : | Totally Enclosed Fan Cooled | Overload Protector : | No |
| Ambient Temperature : | 40 °C | Drive End Bearing Size : | 6207 |
| Opp Drive End Bearing Size : | 6205 | UL : | Recognized |
| CSA : | Y | CE : | Y |
| IP Code : | 55 |
Technical Specifications
| Electrical Type : | Squirrel Cage Induction Run | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Reversible |
| Mounting : | Round | Motor Orientation : | HORIZONTAL |
| Drive End Bearing : | BALL | Opp Drive End Bearing : | BALL |
| Frame Material : | Rolled Steel | Shaft Type : | T |
| Overall Length : | 14.47 in | Frame Length : | 9.00 in |
| Shaft Diameter : | 1.125 in | Shaft Extension : | 2.75 in |
| Assembly/Box Mounting : | F1 ONLY | UPC : | 691720051832 |
| Weight : | 78.00 LB |
Speed Characteristics
| Curvepoint | Current (Amps) | Current (%) | Torque (ft-lbs) | Torque (%) | Speed (RPM) | Rated Output (KW) | Power Factor (%) | Rated Output (Hp) |
| Break-Down | 21.50 | 551.0 | 36.00 | 404.0 | 0 | 0.00 | 0.0 | 3.00 |
| Locked-Rotor | 33.50 | 859.0 | 22.50 | 253.0 | 0 | 0.00 | 0.0 | 3.00 |
| Pull-Up | 33.00 | 846.0 | 21.00 | 236.0 | 0 | 0.00 | 0.0 | 3.00 |
| Full Load | 3.90 | 100.0 | 8.90 | 100.0 | 1,770 | 0.00 | 80.5 | 3.00 |
Load Characteristics
- % of Rated Load
- Current (Amps)
- Rated Output (KW)
- Efficiency (%)
- Power Factor (%)
- Speed (RPM)
- Temp. rise @ FL
- Torque (ft-lb)
- 0 %
- 1.90
- 0.105
- 0.0
- 6.9
- 1,798
- 0.0
- 0.00
- 25 %
- 2.10
- 0.693
- 80.8
- 41.4
- 1,792
- 0.0
- 2.20
- 50 %
- 2.56
- 1.278
- 87.7
- 62.7
- 1,785
- 0.0
- 4.42
- 75 %
- 3.18
- 1.870
- 89.6
- 73.8
- 1,777
- 0.0
- 6.64
- 100 %
- 3.90
- 2.500
- 89.5
- 80.5
- 1,770
- 40.0
- 8.91
- 115 %
- 4.40
- 2.862
- 89.9
- 81.6
- 1,766
- 47.0
- 10.26
- 125 %
- 4.73
- 3.129
- 89.5
- 83.0
- 1,755
- 60.0
- 11.20
- 150 %
- 5.61
- 3.787
- 88.5
- 84.7
- 1,750
- 0.0
- 13.49
