Features
- Designed with the exclusive Inverter Rated Insulation System (IRIS)
- Provides superior protection against voltage spikes induced by variable frequency drives
- Double shielded motor ball bearings
- Needle bearings in the parallel shaft gearboxes
- Steel conduit box provided as Standard
- Finished in high gloss hardened black enamel paint
General Specifications
| UPC: | 691720346488 | Weight: | 26.00 LB |
| Packaged Length: | 19.5 IN | Packaged Width: | 10.44 IN |
| Packaged Height: | 10.88 IN |
Nameplate Specifications
| Output HP: | 0.25 Hp | Output KW: | 0.19 kW |
| Frequency: | 60 Hz | Voltage: | 208-230/460 V |
| Current: | 1.2/0.60 A | Speed: | 85 rpm |
| Service Factor: | 1 | Phase: | 3 |
| Duty: | Continuous | Insulation Class: | F |
| KVA Code: | L | Frame: | 42Y |
| Enclosure: | Totally Enclosed Fan Cooled | Thermal Protection: | No |
| Ambient Temperature: | 40 °C | Drive End Bearing Size: | 6203 |
| Opp Drive End Bearing Size: | 6201 | UL: | Recognized |
| CSA: | Y | CE: | N |
Technical Specifications
| Rotation: | Reversible | Mounting: | Special |
| Shaft Type: | Parallel | Overall Length: | 13.07 in |
| Frame Length: | 6.00 in | Shaft Diameter: | 0.750 in |
| Shaft Extension: | 1.625 in |
Speed & Load Characteristics
