| Product Specifications | |
|---|---|
| Product Style | Standard Locking.
|
| Amperage | 30A
|
| Device Type | Flush Receptacle.
|
| Poles and Wires | 4 Pole, 4 Wire.
|
| Voltage | 3ph 120/208V AC
|
| Product Variation | Standard.
|
| Color | Black.
|
| Configuration Type | L18-30
|
| Base | Reinforced Thermoplastic Polyester.
|
| Face | Nylon.
|
| Terminals | 0.40" (1.0) Copper Alloy.
|
| Terminal Clamp | 0.40" (1.0) Copper Alloy.
|
| Ground Contact | 0.40" (1.0) Copper Alloy.
|
| Ground Shunt | .015" (.3) Copper Alloy.
|
| Mounting Strap | .050" (1.3) Steel (Nickel-Plated).
|
| Back Plate | .040" (1.0) Plated Copper Alloy.
|
| Terminal Screws | #10 Bronze.
|
| Self Ground Clip | Stainless Steel.
|
| Mounting Screws | Plated Steel.
|
| Dielectric Voltage | Withstands 3500V per UL498.
|
| Max Working Voltage | 600V AC or 250V DC.
|
| Current Interrupting | Certified for current interrupting at full rated current.
|
| Temperature Rise | Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% rated current for either AC or DC applications per UL498
|
| Terminal Identification | (X, Y Z Brass Hot) (G, Green, Grounding) (W, Silver, Neutral).
|
| Terminal Accommodation | #14-#8 AWG solid or stranded copper wire.
|
| Product Identification | Ratings and NEMA identification are permanently marked on device.
|
| Flammability | UL 94 V2 Minimum.
|
| Operating Temperatures | -40 deg C to 85 deg C (continuous w/o impact).
|
| UL Standard | UL Listed to Standard 498 (Attachment Plug and Receptacles).
|
| CSA Standard | Certified to CSA Standard C22.2 No.42M1984 (General Use Receptacles) and C22.2 No. 182.2M1987 (Industrial Locking Type, Special Use Attachment Plugs, Receptacles and Connectors) where applicable.
|
| UL Listing File | Ul Listed File #E2258- Guide #RTRT
|
| CSA Certification File | CSA Certified File #LR16215- Guide #365-E-1.
|
| Fed Spec | Federal Specifications WC596 (where applicable).
|
| Complies with: | Complies with NEMA Standards WD-1, WD-6 and UL 498.
|
| Overseas Apporvals | NOM, CE.
|
