AC Horsepower Ratings
Horsepower Rating: 1/2 HP
Electrical Specifications
Amperage: 15 A
Current Interrupting: Certified for current interrupting at full rated current
Dielectric Voltage: Withstands 2000V per UL498
Grounding: Grounding
Pole: 2
Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current
Voltage: 125 VAC
Wire: 3
Environmental Specifications
Environment: Dry
Flammability: Rated HB or better UL94
Operating Temperature: -40°C to 60°C
Material Specifications
Assembly Screws: Steel, Zinc Plated
Back Cover: Thermoplastic
Blades/Contacts: Solid Brass
Body Material: Impact Modified Nylon
Clamp Insert: Nylon
Color: Black-White
Cord-Clamp: Nylon
Terminal Screws: Brass
Wire Module: Nylon
Mechanical Specifications
Cord Range: 0.230 to 0.685
Product ID: Ratings and NEMA I.D. permanently marked on device
Terminal Accom.: 18-10 AWG
Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral
Wire Gauge: 18-10 AWG
Product Features
Brand: Black and White
Color: Black-White
NEMA: L5-15P
Standards and Certifications
ANSI: C-73
CSA C22.2 No. 42: File LR-406
NEMA: WD-6
NOM Certified: 057
UL Fed Spec WC-596: File E13393
Warranty: Lifetime Warranty
