| product or component type |
Circuit breaker |
|
|---|---|---|
| range of product |
PowerPact H |
|
| Trip Unit Type |
Thermal-magnetic |
|
| breaking capacity code |
D |
|
| Line Rated Current |
35 A |
|
|---|---|---|
| Number of Poles |
2P |
|
| Interrupt Rating |
18 kA at 480 V AC 25 kA at 240 V AC 14 kA at 600 V AC 20 kA at 250 V DC |
|
| System Voltage |
250 V DC 600 V AC |
|
| continuous current rating |
80 % |
|
| mounting mode |
Unit mount |
|
| electrical connection |
Lugs load Lugs line |
|
| Wire Gauge |
AWG 14...AWG 3/0 (aluminium/copper) |
|
| magnetic hold current |
400 A |
|
| magnetic tripping current |
850 A |
|
| height |
6.4 in |
|
| width |
2.74 in |
|
| depth |
4.36 in |
|
| product certifications |
CE CSA IEC UL listed |
|
|---|---|---|
| ambient air temperature for operation |
104 °F (40 °C) |
|
| Category |
01110 - HD,JD UNIT MT BREAKER/SWITCH |
|
|---|---|---|
| Discount Schedule |
DE2 |
|
| GTIN |
00785901458937 |
|
| Nbr. of units in pkg. |
1 |
|
| Package weight(Lbs) |
3.04 |
|
| Returnability |
Y |
|
| Country of origin |
US |
|
