Features
Features
- Double sealed ball bearings
- Fully gasketed
- Auto protector
General Specifications
General Specifications
| Model : | Catalog No : | C044A | |
| Part Description : | 1/2,1700,TE,48Z,1/60/115/230 | Category : | Direct Drive Fan |
| Stock : | Yes |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 1/2 Hp | Output KW : | 0.37 kW |
| Frequency : | 60 Hz | Voltage : | 115/230 V |
| Current : | 5.5/2.8 A | Speed : | 1700 rpm |
| Service Factor : | 1 | Phase : | 1 |
| Duty : | Air Over | Insulation Class : | B |
| Frame : | F48Z | Enclosure : | Totally Enclosed |
| Overload Protector : | Automatic | Ambient Temperature : | 40 °C |
| UL : | Recognized | CSA : | Y |
| CE : | N |
Technical Specifications
Technical Specifications
| Electrical Type : | Permanent Split Capacitor | Starting Method : | Across The Line |
| Poles : | 4 | Rotation : | Reversible |
| Mounting : | Resilient Base | Drive End Bearing : | Ball |
| Opp Drive End Bearing : | Ball | Frame Material : | Rolled Steel |
| Shaft Type : | Flat | Overall Length : | 11.00 in |
| Frame Length : | 6.50 in | Shaft Diameter : | 0.500 in |
| Shaft Extension : | 3.14 in | UPC : | 786674015082 |
| Weight : | 24.00 LB |
