Features
- High starting torque
- Manual reset thermal protector
- Torque switch and governor
General Specifications
| UPC: | 786674061362 | Weight: | 25.00 LB |
| Packaged Length: | 12.88 IN | Packaged Width: | 9.81 IN |
| Packaged Height: | 9.81 IN |
Nameplate Specifications
| Output HP: | 3/4 Hp | Output KW: | 0.56 kW |
| Frequency: | 60 Hz | Voltage: | 208-230/460 V |
| Current: | 2.4-2.4/1.2 A | Speed: | 1725 rpm |
| Service Factor: | 1 | Phase: | 3 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 56N | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | Thermally Protected | Ambient Temperature: | 40 °C |
| UL: | Recognized | CSA: | Y |
| CE: | N |
Technical Specifications
| Electrical Type: | Polyphase | Starting Method: | Across The Line |
| Poles: | 4 | Rotation: | Reversible Counterclockwise |
| Mounting: | Round | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Flat | Overall Length: | 10.78 in |
| Frame Length: | 5.13 in | Shaft Diameter: | 0.500 in |
| Shaft Extension: | 1.75 in |
