Features
- Mechanically locked bearing on shaft end
- Double sealed ball bearings
- Keyed shaft
General Specifications
| UPC: | 786674071217 | Weight: | 21.00 LB |
| Packaged Length: | 16 IN | Packaged Width: | 8 IN |
| Packaged Height: | 10 IN |
Nameplate Specifications
| Output HP: | 3.0 Hp | Output KW: | 2.2 kW |
| Frequency: | 60/50 Hz | Voltage: | 230/460 V |
| Current: | 7.2/3.6 A | Speed: | 3450 rpm |
| Service Factor: | 1.15 | Phase: | 3 |
| Duty: | Continuous | Insulation Class: | B |
| Frame: | 56C | Enclosure: | Open Drip Proof |
| Thermal Protection: | No | Ambient Temperature: | 40 °C |
| UL: | Recognized | CSA: | N |
| CE: | Y |
Technical Specifications
| Electrical Type: | Polyphase | Starting Method: | Across The Line |
| Poles: | 2 | Rotation: | Reversible |
| Mounting: | Round | Drive End Bearing: | Ball |
| Opp Drive End Bearing: | Ball | Frame Material: | Rolled Steel |
| Shaft Type: | Keyed | Overall Length: | 14.03 in |
| Frame Length: | 8.00 in | Shaft Diameter: | 0.625 in |
| Shaft Extension: | 2.07 in |
