Features
Features
- Weatherproof features for washdown
- Cast iron NEMA "C" end bracket
- Stainless steel shaft
- Auto overload protector
General Specifications
General Specifications
| Model : | Catalog No : | B582 | |
| Part Description : | 3/4,3450,TENV,56HCZ,1/60/208-230 | Category : | Milk Pump Duty |
| Stock : | Yes |
Nameplate Specifications
Nameplate Specifications
| Output HP : | 3/4 Hp | Output KW : | 0.56 kW |
| Frequency : | 60 Hz | Voltage : | 208-230 V |
| Current : | 4.0-3.8 A | Speed : | 3450 rpm |
| Service Factor : | 1 | Phase : | 1 |
| Duty : | Continuous | Insulation Class : | B |
| Frame : | L56HCZ | Enclosure : | Totally Enclosed Non Ventilated |
| Overload Protector : | Thermally Protected | Ambient Temperature : | 40 °C |
| UL : | Recognized | CSA : | Y |
| CE : | N |
Technical Specifications
Technical Specifications
| Electrical Type : | Permanent Split Capacitor, Single Or Dual Voltage | Starting Method : | Across The Line |
| Poles : | 2 | Rotation : | Clockwise |
| Mounting : | Rigid Base | Drive End Bearing : | Ball |
| Opp Drive End Bearing : | Ball | Frame Material : | Rolled Steel |
| Shaft Type : | Keyed | Overall Length : | 12.20 in |
| Frame Length : | 6.25 in | Shaft Diameter : | 0.625 in |
| Shaft Extension : | 2.17 in | UPC : | 786674012500 |
| Weight : | 36.00 LB |
